PLC NSF

See PLC NSF Products

The 1/4" flow PLC Series is proven worldwide in thousands of applications and offers the widest selection of sizes and configurations. PLC quick disconnect couplings are injection molded from acetal thermoplastic and are resistant to most mild chemical solutions.

These couplings offer the flexibility of multiple configurations and terminations and mate with both LC metal and PLC12 polypropylene couplings. NSF-listed versions are suitable for use with beverage and condiment lines.

The PLC Series is also available with optional RFID (Radio Frequency Identification) capability.

Assets & Downloads

Features Benefits
Colder thumb latch One-hand connection and disconnection
Integral terminations

Fewer leak points, shorter assemblies,

faster installations
Clicks when connected Assurance of a reliable connection
Compatible Mates with LC and PLC12 Series couplings



Specifications & CV Value

Operating Conditions (Fluid Transfer)

Pressure: Vacuum to 120 psi, 8.3 bar
Temperature: -40°F to 180°F continuous, -40°C to 82°C continuous

Materials

Main components and valves: Acetal
Thumb Latch: Stainless steel
Valve spring: 316 stainless steel
External springs and pin: Stainless steel
O-rings: Buna-N

Other

Color: Natural white, others available
Tubing range: 1/4" to 3/8", 6.4mm to 9.5mm

JG® Tubing Specifications

Tube tolerances: 1/4" OD, +0.001/-0.004
3/8" OD, +0.001/-0.004
Tube Types (Plastic tube): Polyethylene, nylon, polyurethane
(Metal tube): Brass, Copper and mild steel

Cv Value

Cv ~ 1.40 (20.17) max
Cv ~ 0.82 (11.82) max
Cv ~ 0.51 (7.35) max
Cv values are based on gpm and psi, and Ipm and bar (shown in parentheses).
For soft or thin wall tubing with JG terminations, tube supports are recommended
WARNING: Pressure, temperature, chemicals and operating environment can affect the performance of couplings. It is the customer’s responsibility to test the suitability of Colder products in their own application conditions. Use the graphs above as a guide.

Validation Reports

Extractables Reports

Products

Body

20400

1/4 NPT Non-Valved Coupling Body (PLC10004 NSF)

20600

3/8 NPT Valved Coupling Body (PLCD10006 NSF)

20800

3/8 Hose Barb Valved In-Line Coupling Body (PLCD17006 NSF)

21000

1/4 NPT Valved Coupling Body (PLCD10004 NSF)

21100

1/4 Hose Barb Valved Panel Mount Coupling Body (PLCD16004 NSF)

22100

1/4 Hose Barb Valved In-Line Coupling Body (PLCD17004 NSF)

22300

3/8 JG Valved In-Line Coupling Body (PLCD14006 NSF)

22500

1/4 Hose Barb Non-Valved In-Line Coupling Body (PLC17004 NSF)

22600

3/8 NPT Non-Valved Coupling Body (PLC10006 NSF)

22900

1/4 JG Valved In-Line Coupling Body (PLCD14004 NSF)

23200

1/4 PTF Non-Valved In-Line Coupling Body (PLC13004 NSF)

24300

1/4 PTF Valved In-Line Coupling Body (PLCD13004 NSF)

24500

3/8 PTF Valved In-Line Coupling Body (PLCD13006 NSF)

26700

3/8 Hose Barb Valved Panel Mount Coupling Body (PLCD16006 NSF)

28200

1/4 JG Valved Panel Mount Coupling Body (PLCD11004 NSF)

31600

1/4 BSPT Valved Coupling Body (PLCD10004BSPT NSF)

Insert

20100

3/8 Hose Barb Non-Valved In-Line Coupling Insert (PLC22006 NSF)

20200

3/8 Hose Barb Non-Valved Elbow Coupling Insert (PLC23006 NSF)

20300

1/4 NPT Non-Valved Coupling Insert (PLC24004 NSF)

21400

3/8 Hose Barb Valved In-Line Coupling Insert (PLCD22006 NSF)

21500

1/4 Hose Barb Valved In-Line Coupling Insert (PLCD22004 NSF)

22000

1/4 NPT Valved Coupling Insert (PLCD24004 NSF)

22200

3/8 NPT Valved Coupling Insert (PLCD24006 NSF)

22400

1/4 Hose Barb Non-Valved In-Line Coupling Insert (PLC22004 NSF)

23300

1/4 PTF Non-Valved In-Line Coupling Insert (PLC20004 NSF)

24700

1/4 JG Valved In-Line Coupling Insert (PLCD29004 NSF)

24800

3/8 JG Non-Valved In-Line Coupling Insert (PLC29006 NSF)

24900

3/8 JG Valved In-Line Coupling Insert (PLCD29006 NSF)

26000

1/4 PTF Valved Panel Mount Coupling Insert (PLCD40004 NSF)

26600

1/4 Hose Barb Valved Panel Mount Coupling Insert (PLCD42004 NSF)

30400

3/8 NPT Non-Valved Coupling Insert (PLC24006 NSF)

30900

3/8 PTF Valved Panel Mount Coupling Insert (PLCD40006 NSF)

31200

3/8 Hose Barb Non-Valved Panel Mount Coupling Insert (PLC42006 NSF)
