    AseptiQuik X

    See AseptiQuik X Products

    AseptiQuik® X large format 1" connectors provide quick and easy sterile connections for high flow applications, even in non-sterile environments. AseptiQuik X's “TWIST-PULL-TWIST” design enables users to quickly transfer large volumes of media easily with less risk of operator error. The connector's robust design provides reliable performance without the need for clamps, fixtures or tube welders. Biopharmaceutical manufacturers can now make 1” sterile connections with the quality and market availability they expect from the leader in single-use connection technology.

    Assets & Downloads

    Features Benefits
    TWIST-PULL-TWIST Design Intuitive  three-step connection process reduces risk of operator error
    Membrane Pull Tabs Ensure simultaneous and secure removal of both membranes
    Robust Construction Repeatable and reliable performance with no additional hardware required
    Integrated Lock Ring Secures final connection preventing disassembly
    CPC Click Audible confirmation of completed assembly steps

    Specifications & CV Value

    Operating Conditions (Fluid Transfer)

    Pressure: Up to 60 psi, 4.1 bar
    Temperature: 39°F to 104°F (4°C to 40°C)
    Typical Flow Rate: Cv~14.4 max


    Main Components: Polycarbonate (white)
    Lock Ring: Polycarbonate, PVDF (blue)
    Pull Tabs: Polycarbonate (blue, standard version), USP Class VI, ADCF
    Polycarbonate (white, HT version), USP Class VI, ADCF
    Caps: Polypropylene (clear), USP Class VI, ADCF
    Seals: Silicone (clear), platinum-cured, USP Class VI, ADCF
    Membrane: Polyethylene (standard version), USP Class VI, ADCF
    Hydrophobic polyethersulfone (HT version), USP Class VI


    Gamma: Up to 50kGy irradiation
    AutoClave: High Temp (HT) Version: Up to 266°F (130°C) for 30 minutes


    Termination Size: 3/4" and 1" ID hose barb (19.0mm and 25.4mm), 1-1/2"

    Cv Value

    Cv~14.4 max
    Cv values are based on gpm and psi, and Ipm and bar (shown in parentheses).
    WARNING: Pressure, temperature, chemicals and operating environment can affect the performance of couplings. It is the customer’s responsibility to test the suitability of Colder products in their own application conditions.

    Validation Reports

    Extractables Reports




    3/4 Hose Barb AseptiQuik X Body, High Temperature


    1 Hose Barb AseptiQuik X Body, High Temperature


    1-1/2 Sanitary AseptiQuik X Body, High Temperature



    3/4 Hose Barb AseptiQuik X Insert, High Temperature


    1 Hose Barb AseptiQuik Insert, High Temperature


    1-1/2 Sanitary AseptiQuik X Insert, High Temperature
