    AseptiQuik G DC

    See AseptiQuik G DC Products

    The AseptiQuik® G DC Series Connector is the first all-in-one, genderless, single-use connection technology to offer both a sterile connection and a sterile disconnection. With the AseptiQuik G DC connector, manufacturers can make quick and easy sterile connections, even in non-sterile environments.

    The intuitive Flip - Click - Pull design of the AseptiQuik G DC connector enables users to transfer media easily with less risk of operator error. After transfer is complete, a simple two-step disconnection maintains media sterility by preventing external organisms from entering into the media flow path.

    The connector's robust design and automatic shutoff valves provide reliable performance without the need for clamps, fixtures or tube welders.

    Assets & Downloads

    Features Benefits
    Genderless Eases single-use systems specifications with one part number for both halves
    FLIP - CLICK - PULL Intuitive  three-step connection process reduces risk of operator error
    Simple Two-Step Disconnection Maintains media sterility in each half by preventing external organisms from entering the flow path
    Membrane Pull Tabs Ensure simultaneous and secure removal of both membranes
    Automatic Shutoff Valves Eliminate the need for pinch clamps or tube welders
    Protective Thumb Latch Cover Eliminates accidental disconnects
    Alloy C-276 internal flow path spring

    Enables broader application compatibility

    Specifications & CV Value

    Operating Conditions (Fluid Transfer)

    Pressure: Up to 60 psi, 4.1 bar Up to 75 psi, 5.1 bar for 48 hours
    Temperature: 34°F to 104°F (1°C  to 40°C)
    Typical Flow Rate: Cv Value Range: 0.8 to 1.90 for AseptiQuik G DC hose barb terminations

    Materials

    Connector: Polycarbonate (white), USP Class VI, ADCF
    Thumblatch: Polycarbonate (blue), USP Class VI, ADCF
    Pull Tabs/Caps: Polycarbonate (blue), USP Class VI, ADCF
    Seals: Silicone (clear), platinum-cured, USP Class VI, ADCF
    Membrane: Polyethylene
    Springs: Alloy C-276

    Sterilization

    Gamma: Up to 50 kGy irradiation

    Other

    Termination Size: 1/4", 3/8", 1/2" hose barb (6.4mm, 9.5mm, 12.7mm)

    Cv Value

    CV Value Range: 0.8 - 1.90
    Cv values represent the approximate expected flow rate in gallons per minute of water at room temperature for a 1 PSI pressure drop. The flow is generally constrained by the smallest diameter, which in some cases will be the termination diameter and not the Nominal Flow Path.
    WARNING: Pressure, temperature, chemicals and operating environment can affect the performance of couplings. It is the customer’s responsibility to test the suitability of Colder products in their own application conditions.
