    See NS212 Products

    NS212 Series couplings were built on the company's proven platform of non-spill valves designed to provide fast, safe and virtually leak-free fluid line connections. NS212 is an easy, twist-to-connect coupling with an integrated locking mechanism and double-sided non-spill shutoff valves. The NS212 is also chemically resistant making it ideal for a diverse range of applications.

    Assets & Downloads

    Features Benefits
    Efficient, non-spill design Disconnect under pressure with no spills
    Multiple seal materials

    Broad chemical compatibility for diverse applications

    Twist-to-connect locking

    Easy, non-spill connections in tight


    Compact design

    High flow in a small connector

    Ultra low air inclusion

    Minimizes contaminants, reduces the need to purge lines



    Specifications & CV Value

    Operating Conditions (Fluid Transfer)

    Pressure: Vacuum to 45 psi, 3.1 bar
    Temperature: 32°F to 120°F (0°C to 49°C)
    Flow capacity: Cv~0.45


    Main components and valves: Glass-filled polypropylene
    Valve spring: 316 Stainless steel
    Seal material: EPDM (FKM/Simriz FFKM optional)


    Color: Gray with black accent standard
    Tubing Sizes: 1/8" to 1/4" (3.2mm to 6.4mm)
    Spillage: <0.025 cc per disconnect
    Inclusion: 0.009 cc per connect

    Cv Value

    Cv ~0.45
    Cv values are based on gpm and psi, and Ipm and bar (shown in parentheses).
    WARNING: Pressure, temperature, chemicals and operating environment can affect the performance of couplings. It is the customer’s responsibility to test the suitability of Colder products in their own application conditions. Use the graphs above as a guide.
